Standard

IEEE 802.11 ax/ac/n/g/b/a

MIMO

MU-MIMO

Wireless speed

2.4GHz: 575 Mbps

5GHz: 1200 Mbps

Frequency band

2.4 GHz:

USA (FCC): 2.412 to 2.462 GHz

Europe (ETSI): 2.412 to 2.472 GHz

5 GHz:

USA (FCC): 5.15 to 5.35 GHz; 5.470 to 5.850 GHz

European (ETSI): 5.15 to 5.35 GHz; 5.470 to 5.725 GHz

Bandwidth

20-, 40-, 80-MHz

Conducted typical transmit output power^*1

US (2.4GHz/5GHz):

23/26 dBm

EU (2.4GHz/5GHz):

20/25 dBm

Antenna type

Internal Antenna

Antenna gain

2.4 GHz: 3 dBi, 2x2:2SS

5GHz: 4 dBi, 2x2:2SS

Minimum receive sensitivity

Min. Rx sensitivity up to -99 dBm

Band steering

Yes

WDS/Mesh^*2

Yes

Fast roaming

Pre-authentication, PMK caching, and 802.11r/k/v

DCS

Yes

Load balancing

No

Encryption

WPA Personal

WPA2 Personal

WPA2-PSK Personal

WPA3 Personal

Authentication

WPA

WPA2-Enterprise

EAP

IEEE 802.1X

RADIUS authentication

Access management

L2-isolation

MAC filtering

Rogue AP detection

IPv6

Yes

VLANs

Yes

WMM

Yes

U-APSD

Yes

Operating mode

Nebula cloud managed

Standalone

ZON Utility

Discovery of Zyxel switches, APs and gateways

Centralized and batch configurations:

IP configuration

IP renew

Device reboot

Device locating

Web GUI access

Firmware upgrade

Password configuration

Web UI/CLI

Yes

SNMP

NO

Item

Dimensions (WxDxH)(mm/in.)
140 x 140 x 37.5/5.51 x 5.51 x 1.48

Weight (g/lb.)
290/0.64

Packing

Dimensions (WxDxH)(mm/in.)
240 x 155 x 60/9.45 x 6.10 x 2.36

Weight (g/lb.)
600/1.32

Included accessories

Power adapter

Mount plate

Mounting screws

MTBF (hr)

1,010,980

Ethernet port

1 x 10/100/1000M LAN

Power

Power Adapter: AC 100 - 240V - 50/60 Hz 0.3A; Output: DC +12V 1.5A

PoE (802.3at): power draw 16 W

Operating

Temperature
0°C to 50°C/32°F to 122°F

Humidity
10% to 90% (non-condensing)

Storage

Temperature
-40°C to 70°C/-40°F to 158°F

Humidity
10% to 90% (non-condensing)
