Standard

• IEEE 802.3u 100BASE-TX Fast Ethernet
• IEEE802.3ab 1000BASE-T
• IEEE 802.3bz 2.5GBASE-T
• IEEE 802.3x full duplex operation and flow control
• IEEE 802.1p QoS
• IEEE 802.3 Nway auto-negotiation

Performance

• Switching capacity:
  • MG-105: 25 Gbps
  • MG-108: 40 Gbps
• Switching forwarding rate:
  • MG-105: 18.6 Mpps
  • MG-108: 29.8 Mpps
• MAC address table: 16 K
• Packet buffer: 12Mb
• Jumbo frame supports up to 12 KB

Features

• 100M, 1G and 2.5G ports for multi speed
• Fanless and quiet
• Plug and Play, Easy use and Quick Install
• Desktop and Wall mount
• Auto-MDI/MDIX in all ports

Item dimensions (WxDxH):

• MG-105: 160 x 110 x 26 mm(6.3" x 4.33" x 1.02")
• MG-108: 240 x 106 x 26 mm(9.45" x 4.13" x 1.02")

Item weight:

• MG-105: 460g (1.01 lb.)
• MG-108: 640g (1.41 lb.)

Packing dimensions (WxDxH):

• MG-105: 215 x 133 x 79 mm (8.46" x 5.24" x 3.11")
• MG-108: 256 x 132 x 78 mm (10.08" x 5.2" x 3.07")

Packing weight:

• MG-105: 919.6g (2.03 lb.)
• MG-108: 1,122g (2.47 lb.)

Operating Environment

• Temperature: 0°C to 40°C (32°F to 104°F)
• Humidity: 10% to 90% (Non-condensing)

Storage Environment

• Temperature: -40°C to 70°C (-40°F to 158°F)
• Humidity: 5% to 95% (Non-condensing)

• CE, EAC, FCC, BSMI Class B

• Switch
• Power adapter
• Quick Start Guide
• Safety warning and doc.
