Video and Audio | |
IP Video Input | 8-Channel |
Incoming Bandwidth | 80 Mbps |
Outgoing Bandwidth | 60 Mbps |
HDMI Output Resolution | 1 Channel, Resolution: 3840x2160/30Hz, 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz |
VGA Output Resolution | 1 Channel, Resolution: 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz |
Video Output Mode | HDMI/VGA Simultaneous Output |
Multi-View Display | 1/4/6/8 |
DECODING | |
Audio Compression | G.711A/G.711U/G.726 |
Decoding Format | H.265+/H.265/ H.264+/H.264 |
Video Compression | H.265+/H.265/ H.264+/H.264 |
Record Resolution | 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
Live View/Playback Resolution | 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/ DCIF/2CIF/CIF/QCIF |
Synchronous Playback | 8 Channel |
Capability | 2-ch @ 8MP, 4-ch @ 4MP, 8-ch @ 2MP |
Record Management | |
Record Mode | Manual Recording, Scheduling Recording, Motion Detection Recording |
Playback Mode | Instant Playback, Regular Playback, Tag Playback, Event Playback |
Backup Mode | Regular Backup, Video Clip Backup |
Playback Function | Play, Pause, Stop, Fast Forward, Fast Backward, Play By Frame, Full Screen, Video Clip, Export Clip, Digital Zoom, Lock Recording, Audio On/Off |
NETWORK | |
Protocol | TCP/IP, DHCP, DNS, NTP, UPnP |
Mobile Phone Access | Android, iOS |
Incoming Bandwith | 80 Mbps |
Outgoing Bandwidth | 60 Mbps |
Web Browser | Chrome (57+), Firefox (52+), Edge (91+) |
Interoperability | ONVIF, CGI |
External Interface | |
Network Interface | 1 RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface |
USB Interface | 2× USB 2.0 |
Audio Interface | 1, Audio In; 1, Audio Out |
Alarm In/Out | N/A |
Serial Interface | N/A |
Power | 1× DC Jack |
Reset Button | 1 |
Speaker | N/A |
eSATA | N/A |
HDMI | 1 |
VGA | 1 |
HARD DISK | |
SATA | 1 SATA Interface |
Capacity | Up to 16 TB |
PoE | |
Standard | 802.3at/af Compliant |
Interface | 1- 8, RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface |
PoE Budget | 53 W Available for All PoE+ Ports, 30 W Max per Port |
Alarm | |
General Alarm | Motion Detection, Video Tampering, Line-Crossing Detection, Intrusion Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned/Removal Detection, Vehicle Detection, Human Detection, Smart Frame |
Anomaly Alarm | Video Loss, Offline and IP Conflict, Disk Exception, Login Exception, Fan Exception |
Alarm Linkage | Recording, White Light Alarm, Buzzer, Log, Audible Alarm |
INTERFACES | |
Network Interface | 1 RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface |
USB Interface | 2× USB 2.0 |
GENERAL | |
Operating Temperature | -10–55 °C |
Storage Temperature | -40–70 °C |
Storage Humidity | 10%~90% RH Non-Condensing |
Package Contents | VIGI Network Video Recorder Power Adapter HDD Screws Mouse Quick Installation Guide |
Working Temperature | NVR: -10–55 °C Power Adapter: 0–40 °C |
Working Humidity | 10%~90% RH Non-Condensing |
Dimensions( W X D X H ) | 294 × 180 × 44 mm |
PoE | Standard: 802.3af/at PoE Ports: Ports 1-8 PoE Budget: 53 W |
External Power Supply | 53.5V DC/1.31 A |
Net Weight | 1.12 Kg |
Gross Weight | 2.06 Kg |
Power Supply | 53.5V DC/1.31A |
Power Consumption | 2.38 W (without disk) 12.94 W (with disk) |
Certifications | CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC, HDMI |
VIDEO/IMAGE | |
Video Input | 8-Channel IP Video Input, up to 8 MP Resolution |
Recording Resolution | 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF |
HDMI Output Resolution | 1 Channel, Resolution: 3840x2160/30Hz,1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1024x768/60Hz, 1280x720/60Hz |
VGA Output Resolution | 1 Channel, Resolution: 1920x1080/60Hz,1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz, |
