HARDWARE FEATURES | |
Standards and Protocols | IEEE 802.3i,IEEE 802.3u,IEEE 802.3ab, IEEE802.3z,IEEE 802.3x,IEEE 802.1d, IEEE 802.1s,IEEE 802.1w,IEEE 802.1q,IEEE 802.1p |
Interface | 48 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX) 4 Gigabit SFP Slots |
Network Media | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m) 1000BASE-X: MMF, SMF |
Fan Quantity | Fanless |
Dimensions ( W x D x H ) | 17.3 × 8.7 × 1.7 in. (440 × 220 × 44 mm) |
Mounting | 19" 1U rack mountable |
Max Power Consumption | 32.8 W |
Max Heat Dissipation | 111.9 BTU/h |
PERFORMANCE | |
Bandwidth/Backplane | 104Gbps |
MAC Address Table | 16k |
Packet Buffer Memory | 77.4Mpps |
Jumbo Frame | 9216 Bytes |
SOFTWARE FEATURES | |
Quality of Service | Support 802.1p CoS/DSCP priority Support 8 priority queues Queue scheduling: SP, WRR, SP+WRR Port/Flow- based Rate Limiting IPv6 QoS Voice VLAN |
L2 and L2+ Features | Static Routing DHCP Relay IGMP Snooping V1/V2/V3 802.3ad LACP (Up to 14 aggregation groups, containing 8 ports per group) Spanning Tree STP/RSTP/MSTP BPDU Filtering/Guard TC/Root Protect Loopback detection 802.3x Flow Control LLDP, LLDP-MED |
VLAN | Supports up to 4K VLANs simultaneously (out of 4K VLAN IDs) MAC/Protocol-based VLAN |
Access Control List | L2~L4 package filtering based on source and destination MAC addresses, IP addresses, or TCP/UDP ports IPv6 ACL |
Security | SSH v1/v2 SSL v3/TLS v1 Port Security DHCP Snooping IP-MAC-Port Binding ARP Inspection 802.1x and Radius Authentication AAA Broadcast/Multicast/Unknown-unicast Storm Control Dos Defend |
IPv6 | Dual IPv4/IPv6 stack Multicast Listener Discovery (MLD) Snooping IPv6 neighbor discovery (ND) Path maximum transmission unit (MTU) discovery Internet Control Message Protocol (ICMP) version 6 TCPv6/UDPv6 |
IPv6 Applications | DHCPv6 Client Ping6 Tracert6 Telnet (v6) IPv6 SNMP IPv6 SSH IPv6 SSL Http/Https IPv6 TFTP |
Management | Web-based GUI and CLI management SNMP v1/v2c/v3,compatible with public MIBs and TP-LINK private MIBs RMON (1, 2, 3, 9 groups) CPU Monitoring Port Mirroring Firmware Upgrade: TFTP & Web System Diagnose: VCT SYSLOG & Public MIBS Dual Image |
OTHERS | |
Certification | CE, FCC, RoHS |
Package Contents | T1600G-52TS Power Cord Installation Guide Resource CD Rackmount Kit Rubber Feet |
System Requirements | Microsoft® Windows® XP, Vista™ or Windows 7, Windows 8, MAC® OS, NetWare®, UNIX® or Linux. |
Environment | Operating Temperature: 0℃~40℃ (32℉~104℉); Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
