Standards | • IEEE 802.11ax/ac/n/a 5 GHz • IEEE 802.11ax/n/b/g 2.4 GHz |
Data Interfaces | • 1 x 10/100/1000/2500 Gigabit WAN port • 1 x 10/100/1000/2500 Gigabit LAN port • 3 x 10/100/1000 Gigabit LAN ports • 1 x USB 3.0 • 1148Mbps for 2.4GHz band (802.11ax 40MHz 4x4) • 4804Mbps for 5.0GHz band (802.11ax 160MHz 4x4) • 8 antennas, AX6000 |
LEDs | • Power • Internet • 4 LAN LEDs (LAN 1 - LAN 4) at LAN ports • USB • Wi-Fi • Mesh/WPS |
Buttons | • Power ON/OFF Switch, RESET, WPS/MESH |
WiFi Encryption | • WEP, WPA-PSK, WPA2-PSK, WPA/WPA2-PSK |
Network Security | • Access Control, IP & MAC Binding |
Guest Network | • 45GHz Guest Network / 42.4GHz Guest Network |
WAN Type | • DHCP, Static IP, PPPoE |
Quality of Service | • QoS by Device |
Forwarding | • Virtual Servers, DMZ, UPnP |
Compliance | • CE, FCC, MCMC MTSFB TC T007:2020 SHORT RANGE DEVICES - SPECIFICATIONS (SECOND REVISION) |
IPv6 | • IPv6 and IPv4 dual stack • IPv6 Tunnels: DS-Lite • IPv6 Connection Type: PPPoEv6, DHCPv6, Static IPv6 |
Mesh | • Support 1 Main + 3 Satellite (1 + 3) |
Mobile App | • D-Link Wi-Fi Connect (Android & IOS) - Support LAN & WAN Environment |
DDR/FLASH | • 1G/128MB Single Flash Dual Image |
Operating System | • PC - Microsoft, MacOS • Mobile - Android, Apple iOS, Huawei HarmonyOS |
Management | • Support Quick Installation Wizard • Support configuration saving, and restore to factory configuration • Support firmware upgrading via WEB GUI • Support Syslog monitoring • TR-069/TR-181/TR-143 compliance |
Power Supply | • 12V/3A power supply |
Temperature | • Operating temperature: 0°C — 60°C, Operating humidity: 10-85% (non-condensed) • Storing temperature: -40°C — 80°C, Storing humidity: 5-95% (non-condensed) |
Dimensions | • Device: 267mm x 267mm x 167mm • Box: 405mm x 340mm x 186mm |
Weight | • Device: 680g • Box: 1260g (with device) |
Certifications | • CE, FCC |
Environment | • Operating Temperature: 0℃~40℃ • Storage Temperature: -40℃~70℃ • Operating Humidity: 10%~90% non-condensing • Storage Humidity: 5%~90% non-condensing |
